SNO1-2111 15A 250V 3 Pin Medium Toggle Switch On Off On

Feature: The waterproof toggle switch is made of metal and bakelite. The shaft and bracket are both made of Brass Material. Switch with M12X0.75 weatherproof Boot Cap Cover, can effectively protect the switch. Delicate appearance with strong Construction. Look chic and high-end on your equipment.
Function: Waterproof toggle switch with 2 pin SPST design (single pole single throw), easy to turn ON OFF. The rating is 30A 12VDC; 15A 250VAC; 20A 125VAC.
Installation: Mounting hole size is 0.48 inches (12.2MM). Each of the terminals has a machine screw for quick connections, The thickness of Terminals is 0.8mm.
Mechanical life: more than 100,000 cycles. Electrical life: more than 10,000 cycles.
Application: Waterproof toggle switch is widely applied to various additional electric equipment inside and outside Auto Car Marine Boat, such as lights, chassis lamp, fog lamps, dome light, etc.

Silver Contact/ 0.8mm Terminal / Brass Handle

Rating : 30A 12V DC ; 20A 125VAC ; 15A 250VAC

Contact R : 50 mΩ max

Insulation R : 500V DC 1000MΩ min

Dielectric Strength : 1 Minute 1500V AC

Operating Temperature : -25℃ ~ +85℃

Electrical Life : ≥10,000 Cycles

Function: SPST 2 Pin ON OFF
